Mixing Plant Automation
'Mixing Plant Automation with FLEXIBLE SPIRAL CONVEYOR'
GRAVIMETRIC DOSAGE IN HIGH SPEED MIXER
One after another, different products are dosed into the weighing hopper. The hopper rests on the 3 installed load cells and is provided with a quick opening butterfly valve at the outlet The connection between the outlet of the dosing conveyors as well as the mixer beyond the hopper occurs with flexible hoses or cloth so as not to affect the weighing process. As soon as all components get into the weighing hopper and the mixer needs a new load, the valve opens to discharge the whole content of the weighing hopper.
Benefits of flexible spiral conveyor
- Dustfree, product sensitive, segregation free, environmentally protective conveying
- Easy installation and shortening of conveying
- Low energy demand
- Good price / value rating
- Conveyance of mixture of several components without any segregation
- Maintenance-free
- Flexible plant design
'Mixing Plant Automation with VACUUM CONVEYOR'
Weighing
Precise and accurate weighing of raw materials and feeding to heater mixer vessel in exact proportion as per formulation recipe data stored in the system.
Mixing
Guaranteeing complete reproducible and consistent dry blend properties and thus minimizing the extrusion scrap rate.
Control
- Entire process sequence controlled through advanced PLC
- HMI for easily setting and changing the process as well the mixing parameters
- Visual program display sequence by means of luminous signals
The PRIMETECH compounding plant automation system works effectively where realisation of high throughput rates is combined with the thought of minimization of labour.
Perfect synchronization of process like material storage, conveying, weighing and mixing are of utmost importance when dealing with complete plant automation solution.
PRIMETECH automated plant system outperforms in all the manner where processes like automatic material handling or complete controlled process sequence are concerned, through highly advanced logic based controllers.
Storage
Ground hopper for dumping of row materials with suitable non-dusting system arrangement.
Conveying
Mechanical spiral / vacuum conveying.
